D SUB PCB Female Four Row

Product Description
Product Attributes
Packaging & Delivery
Product Description
Product Attributes
Model No.: HDP02-F78XXXX

Brand: ANTENK

place of origin: China

Interface Type: D-Sub(Vga)

Housing: Plastic

Pin: Brass

Poles: 8-16

Application: Military Aviation

Certification: Ce

Gender: Female

Material: Brass

Support Card Number: All In One

Operating Frequency: High Frequency

Classification: Fine Pitch Connectors

Packaging & Delivery
Selling Units:
Bag/Bags
Package Type:
TRAY PACKING and TUBE PACKING
Download:
Product Description
Manufacturer :ANTENK ELECTRONICS.,CO LTD.

ANTENK D-Sub connectors / contacts are manufactured in plug or receptacle gender with 50 Ohm impedance. D Sub contacts are available in straight or right angle versions, as well as, mount-less options. These D-Sub contact designs include crimp/solder, solder or solder/solder attachment methods.

Our ISO 9001:2008 and ISO 9001:2015registered production facility ships D subminiature connectors / contacts the same day from the broadest and deepest in stock inventory of RF and microwave parts. Exceptional customer service and technical support are available to assist our customers.

The I/O connection system has been invaluable to electronic applications for many years.These products are used in nearly all application markets, from control and measuring to telecommunications and computer applications. Owing to the combination of various contact types there are numerous possibilities of saving installation space and costs in the interface area. CONEC D-SUB connectors are available in five standard housing sizes in the variants Standard, High Density and Combination with or without filters.

SPECIFICATION

Material:
Housing: Temperature Thermoplastics,PBT+G.F UL 94V-0
Contact: Brass or Bronze
Shell: 0.35T Steel Nickel Plating All Area
Electical Characteristics:
Current Rating :5A

Contact Resistance:20 Milliohms Max

Withstanding Voltage:500V AC For 1 Minute

Insulation Resistance :1000 Mehms Min

Operating Temperature:-55℃ to +125℃



Q: Can you do our own packaging?
A: Yes, you just provide the package design and we will produce what you want. We also have the professional designer can help you do the packaging design.

Q: How many different types of products your company manufactures?
A: Now we have more than 1,000 products. We have a strong advantage of OEM, just give us the actual products or your idea that you want, we will manufacture for you.

Q: When can I get the price?
A: Usually we quote within 8 hours after we get your inquiry.

Q: What's your MOQ?
A: If we have the products in stock, it will be no MOQ. If we need to produce, we can discuss the MOQ according to customer's exact situation.

Q: How long is your delivery time?
A: The general delivery time is 30-45 days after receiving your order confirmation. Anther, if we have the goods in stock, it will only take 1-2 days.

Q: Do you provide sample ? Is it free?
A: If the sample is low value, we will provide the free sample with freight collect. But for some high value samples, we need to collect the sample charge.



ANTENK Electronics Co., Ltd(with the trade mark of "Antenk") was established in 2007. We specialize in producing precise Board to Board,Automotive Connector, Terminal Block Series,Battery Connector,Din41612 Connector,Round hole row needle, round hole row mother, IC Socket,Battery Holders Series, Male Pin Headers Series,Female Pin Headers Series, Modular Jack RJ45 Series,D-Subminiature Connectors Series,Box Header Connector, IDC Socket Connector , SCSI Connectors Series, Power Signal Connector, Wire to Board Connector, Modular Jack, Terminal Block, Wire Harnesses,Cable
