2.54mm Box Header Type

Product Attributes

Model No.: BHDS05 2.54mm Box Header 180°H=9.0 Add Housing Brand: ANTENKInterface Type: AC/DCHousing: PlasticPin: BrassPoles: OtherApplication: OtherCertification: OtherGender: MaleMaterial: BrassSupport Card Number: OtherOperating Frequency: High FrequencyClassification: Other

Supply Ability & Additional Information

Packaging: bag packing,Tube packing, reel packingProductivity: 100000K/monthTransportation: Ocean,AirPlace of Origin: ChinaSupply Ability: 100000K/monthCertificate: ISO9001HS Code: 8536909000 Payment Type: T/T,Paypal: FOB,CIF,EXW,FCA

Packaging & Delivery

Selling Units:

Bag/Bags

Package Type:

bag packing,Tube packing, reel packing

Shenzhen Antenk Electronics Co., Ltd. promoted a 2.54mm Box Header IDC Type Without Mounting Ears connector.

The structure of the wire-to-board connector is simple: place the electrode (contact) in the outer casing (rubber case). There are two types of contacts: rods or tabs of "plugs" and "sockets". Push the plug completely into the socket and cover it to achieve [pairing". (Fig. 1) Generally speaking, the socket is connected to the wire, and the plug is connected to the substrate, but this can be reversed depending on the usage. The connection of wires and contacts is typically accomplished using "pressure bonding" techniques such as crimp terminals. "Pressure welding" can also be used to connect wires and contacts. The pressure welding technique is used for low current connections to simply connect the insulated wires to the contacts, allowing for a full connection. Although this method is convenient, the durability may be reduced. The above two technologies can avoid the overheating caused by soldering technology and protect the connection from damage.

SPECIFICATION

Current Rating: 2.0Amp

Insulation Resistance: 1000MΩ min

Contact Resistance: 20MΩ max

Withstand Voltage: 500V AC/DC

Operating Temperature: -40°C to +105°C

Contact Material: Brass

Contact Plating: Au or Sn Over Ni

Insulator Material: PBT UL 94V-0

Q: What's your tem of the delivery?
A: Our ordinary delivery term is FOB Xiamen. We also accept EXW, CFR, CIF, DDP, DDU etc. We'll offer you the shipping charges and you can choose the one which is the most convenient and effective for you.

Q: What's your after-sale service?

A: Our quality warranty period is one year. Any quality problem will be solved to customer satisfactions.
